METRIC THREAD

Descriptions

Metric threads, the most widely used general-purpose screw threads globally, are defined by the ISO Metric Screw Thread standard (ISO 68). They are characterized by a symmetric V-shape profile with a 60° flank angle.

Designation System

A metric thread is designated by the letter M followed by its nominal major diameter in millimetres. If the pitch is not the standard "coarse" pitch, it is specified after the diameter, separated by an "x" (or a dash).

M8: Refers to a coarse thread with a nominal diameter of 8 mm (and an implied standard pitch of 1.25 mm).
M8x1: Refers to a fine thread with a diameter of 8 mm and a pitch of 1 mm.

Coarse vs. Fine Threads

Metric threads are available in two primary pitch types, which are not related to manufacturing quality.

Coarse Threads:

Feature a larger pitch (distance between threads).
Are the more common and general-purpose type, widely available and suitable for most applications.
Allow for quick assembly and disassembly.

Fine Threads:

Have a smaller pitch, meaning more threads per unit of length.
Offer enhanced strength and better resistance to loosening from vibration.
Require a longer thread engagement and are often found in automotive and aerospace applications.

Specifications

No detailed specifications are available for this product.

Downloads

There are no downloads for this product.

Code	Description	Price	Quantity
HNM03D	M3 HEX DOME NUT 271 In Stock for dispatch	Price Unavailable	- +
HNM04D	M4 HEX DOME NUT 4844 In Stock for dispatch	Price Unavailable	- +
HNM05D	M5 HEX DOME NUT 299 In Stock for dispatch	Price Unavailable	- +
HNM05DP	M5 HEX DOME NUT ZINC PLATED 1042 In Stock for dispatch	£14.30 (exc VAT) per HUND £17.16 (inc VAT) per HUND	- +
HNM06D	M6 HEX DOME NUT 41 In Stock for dispatch	Price Unavailable	- +
HNM06DP	M6 HEX DOME NUT ZINC PLATED 7557 In Stock for dispatch	£1.11 (exc VAT) per HUND £1.33 (inc VAT) per HUND	- +
HNM08D	M8 HEX DOME NUT Out of Stock	£33.00 (exc VAT) per HUND £39.60 (inc VAT) per HUND	- +
HNM08DP	M8 HEX DOME NUT ZINC PLATED 2832 In Stock for dispatch	£27.00 (exc VAT) per HUND £32.40 (inc VAT) per HUND	- +
HNM10D	M10 HEX DOME NUT 61 In Stock for dispatch	£38.40 (exc VAT) per HUND £46.08 (inc VAT) per HUND	- +
HNM10DC	M10 HEX DOME NUT CHROME Out of Stock	£118.44 (exc VAT) per HUND £142.13 (inc VAT) per HUND	- +
HNM10DP	M10 HEX DOME NUT ZINC PLATED 256 In Stock for dispatch	£53.30 (exc VAT) per HUND £63.96 (inc VAT) per HUND	- +
HNM12D	M12 HEX DOME NUT Out of Stock	£32.25 (exc VAT) per HUN £38.70 (inc VAT) per HUN	- +
HNM12DG	M12 HEX DOME NUT GALV 12 In Stock for dispatch	£374.60 (exc VAT) per HUN £449.52 (inc VAT) per HUN	- +
HNM12DP	M12 HEX DOME NUT ZINC PLATED 335 In Stock for dispatch	£61.40 (exc VAT) per HUN £73.68 (inc VAT) per HUN	- +
HNM14D	M14 HEX DOME NUT Out of Stock	Price Unavailable	- +
HNM14DP	M14 HEX DOME NUT ZINC PLATED Out of Stock	£176.00 (exc VAT) per HUN £211.20 (inc VAT) per HUN	- +
HNM16D	M16 HEX DOME NUT 153 In Stock for dispatch	£129.78 (exc VAT) per HUND £155.74 (inc VAT) per HUND	- +
HNM16DG	M16 HEX DOME NUT GALV Out of Stock	£650.00 (exc VAT) per HUND £780.00 (inc VAT) per HUND	- +
HNM16DP	M16 HEX DOME NUT ZINC PLATED 117 In Stock for dispatch	£113.10 (exc VAT) per HUND £135.72 (inc VAT) per HUND	- +
HNM20D	M20 HEX DOME NUT Out of Stock	Price Unavailable	- +
HNM20DG	M20 HEX DOME NUT GALV 71 In Stock for dispatch	£994.00 (exc VAT) per HUND £1,192.80 (inc VAT) per HUND	- +
HNM20DNP	M20 HEX DOME NUT NICKLE PLATED Out of Stock	£357.00 (exc VAT) per HUND £428.40 (inc VAT) per HUND	- +
HNM20DP	M20 HEX DOME NUT ZINC PLATED 20 In Stock for dispatch	£232.00 (exc VAT) per HUND £278.40 (inc VAT) per HUND	- +
HNM24DG	M24 HEX DOME NUT GALV 30 In Stock for dispatch	£2,550.00 (exc VAT) per HUND £3,060.00 (inc VAT) per HUND	- +
HNM24DP	M24 HEXAGON DOMED NUTS ZINC PLATED Out of Stock	£2,000.00 (exc VAT) per HUND £2,400.00 (inc VAT) per HUND	- +
HNM30DP	M30 HEXAGON DOMED NUTS ZINC PLATED Out of Stock	£4,450.00 (exc VAT) per HUND £5,340.00 (inc VAT) per HUND	- +
