WHITWORTH THREAD

Whitworth threads were the world's first national screw thread standard, devised by Sir Joseph Whitworth in 1841. They are an imperial (inch-based) system characterized by a distinct 55° thread angle and rounded roots and crests.

Key Characteristics

  • Thread Angle: All Whitworth threads, including BSW and BSF, have a symmetrical V-profile with a 55° included angle between the thread flanks. This is a key difference from the 60° angle used in modern metric and Unified threads.
  • Thread Profile: The threads feature unique rounded roots and crests, designed to distribute stress effectively and provide excellent fatigue resistance.
  • Designation: Dimensions are specified in imperial units, using inches and "Threads Per Inch" (TPI) rather than metric pitch measurements.
  • Standardization: The standard is codified in British Standard BS 84.

BSW vs. BSF Threads

The Whitworth system encompasses two main series for general engineering:

  • BSW (British Standard Whitworth): This is the original, coarse-pitch thread series, primarily designed for general engineering applications like holding cast iron components or locomotives together. Its coarse pitch provides superior strength in softer materials and resistance to stripping.
  • BSF (British Standard Fine): This series was developed later as a fine-pitch alternative to BSW. BSF threads have the same 55° profile as BSW but a finer pitch, which provides increased core strength and better resistance to loosening from vibration, making it common in automotive and aviation applications before metric standardisation.
Code Description Price Quantity
HRBW019-14 3/16 WH X 14G RIVET BUSH
£42.10 (exc VAT) per HUND
£50.52 (inc VAT) per HUND
-
+
HRBW019-16 3/16 WH X 16G RIVET BUSH
Price Unavailable
-
+
HRBW019-18 3/16 WH X 18G RIVET BUSH
£65.00 (exc VAT) per HUND
£78.00 (inc VAT) per HUND
-
+
HRBW025-14 1/4 WH X 14G RIVET BUSH
£49.90 (exc VAT) per HUND
£59.88 (inc VAT) per HUND
-
+
HRBW025-16 1/4 WH X 16G RIVET BUSH
Price Unavailable
-
+
HRBW025-18 1/4 WH X 18G RIVET BUSH
£65.00 (exc VAT) per HUND
£78.00 (inc VAT) per HUND
-
+
HRBW031-14 5/16 WH X 14G RIVET BUSH
£120.30 (exc VAT) per HUND
£144.36 (inc VAT) per HUND
-
+
HRBW031-16 5/16 WH X 16G RIVET BUSH
Price Unavailable
-
+
HRBW031-18 5/16 WH X 18G RIVET BUSH
£120.30 (exc VAT) per HUND
£144.36 (inc VAT) per HUND
-
+
HRBW037-10 3/8 WH X 10G RIVET BUSH
£219.90 (exc VAT) per HUND
£263.88 (inc VAT) per HUND
-
+
HRBW037-12 3/8 WH X 12G RIVET BUSH
Price Unavailable
-
+
HRBW037-14 3/8 WH X 14G RIVET BUSH
£219.90 (exc VAT) per HUND
£263.88 (inc VAT) per HUND
-
+
HRBW037-16 3/8 WH X 16G RIVET BUSH
£219.90 (exc VAT) per HUND
£263.88 (inc VAT) per HUND
-
+
HRBW037-18 3/8 WH X 18G RIVET BUSH
£219.90 (exc VAT) per HUND
£263.88 (inc VAT) per HUND
-
+
