SCHED 40

SCHED 40

Schedule 40 metric pipe dimensions



Nominal Pipe Size (NPS)

Outside Diameter (mm)

Wall Thickness (mm)


1/2 inch

21.3 mm

2.77 mm


3/4 inch

26.7 mm

2.87 mm


1 inch

33.4 mm

3.38 mm


1 1/4 inches

42.2 mm

3.56 mm


1 1/2 inches

48.3 mm

3.68 mm


2 inches

60.3 mm

3.91 mm


2 1/2 inches

73.0 mm

5.16 mm


3 inches

88.9 mm

5.49 mm


3 1/2 inches

101.6 mm

5.74 mm


4 inches

114.3 mm

6.02 mm


5 inches

141.3 mm

6.55 mm


6 inches

168.3 mm

7.11 mm


8 inches

219.1 mm

8.18 mm


10 inches

273.0 mm

9.27 mm


12 inches

323.8 mm

10.31 mm

Note: For larger pipes, Schedule 40 wall thickness differs from standard weight.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
TUBE200-40W 2" WELDED STEEL TUBE SCH 40 88.9MM OD X 5.49
Out of Stock
Price Unavailable
-
+
TUBE300-40W 3" WELDED STEEL TUBE SCH 40 88.9MM OD X 5.49
Out of Stock
Price Unavailable
-
+
TUBE400-40W 4" WELDED STEEL TUBE SCH 40 114.3MMOD X 6.02
Out of Stock
Price Unavailable
-
+
TUBE600-40W 6" WELDED STEEL TUBE SCH 40 168.3MMOD X 7.11
Out of Stock
Price Unavailable
-
+
TUBE800-40W 8" WELDED STEEL TUBE SCH 40 219.1MMOD X 8.18
3.3 In Stock for despatch
Price Unavailable
-
+
TUBE1000-40W 10" WELDED STEEL TUBE SCH 40 273.0MMOD X 9.27
Out of Stock
Price Unavailable
-
+
