BA THREAD

BA THREAD

BA (British Association) threads are a British standard for small screws and fasteners, primarily used in precision instruments, model engineering, and legacy electrical equipment. Unlike metric threads, they are designated by a number (e.g., 0BA, 2BA, 4BA), where a higher number indicates a smaller diameter.

Key Characteristics

  • Thread Angle: BA threads have a unique, symmetrical V-profile with a 47.5° flank angle. This differs from the 60° angle used by metric and Unified threads, making them non-interchangeable.
  • Thread Profile: The threads feature rounded crests and roots to reduce stress concentrations and enhance durability in delicate applications.
  • Sizing System: The system is based on a geometric progression, with the pitch of each successive size (higher number) being approximately 0.9 times the pitch of the lower number.
  • Standardization: They are specified by British Standard BS 93:2008, which defines dimensions and tolerances for sizes 0BA to 16BA.

No detailed specifications are available for this product.

There are no downloads for this product.

Code Description Price Quantity
BSBA0150 0BA X 1.1/2 BRASS HEX SET
Out of Stock
Price Unavailable
-
+
BSBA2050 2BA X 1/2 BRASS HEX SET
Out of Stock
£59.40 (exc VAT) per HUND
£71.28 (inc VAT) per HUND
-
+
BSBA2087 2BA X 7/8 BRASS HEX SET
4 In Stock for dispatch
Price Unavailable
-
+
BSBA2100 2BA X 1" BRASS HEX SET
Out of Stock
£127.60 (exc VAT) per HUND
£153.12 (inc VAT) per HUND
-
+
BSBA2150 2BA X 1.1/2 BRASS HEX SET
19 In Stock for dispatch
£342.00 (exc VAT) per HUND
£410.40 (inc VAT) per HUND
-
+
BSBA2200 2BA X 2" BRASS HEX SET
Out of Stock
£400.00 (exc VAT) per HUND
£480.00 (inc VAT) per HUND
-
+
BSBA4037 4BA X 3/8 BRASS HEX SET
Out of Stock
£111.90 (exc VAT) per HUND
£134.28 (inc VAT) per HUND
-
+
BSBA4150 4BA X 1.1/2 BRASS HEX SETS
30 In Stock for dispatch
£523.00 (exc VAT) per HUND
£627.60 (inc VAT) per HUND
-
+
